HD-100B Welding Current Monitor

HD-100B current welding detector is a resistance welding detector independently developed by Huandian. The main components are imported products to ensure the reliability and stability of the product. Through the digital collection and monitoring of key values ​​in the welding process, welding analyzer realizes the real-time collection, display, over-limit alarm and network communication of key values ​​such as welding current and voltage of a single resistance welding device or multiple resistance welding devices during the welding process, and records and analyzes the data and traces the history. Achieve the purpose of standardizing welding operations and improving welding quality.

1.Strong applicability

Suitable for various types of resistance welding machines, including AC spot welding machines, DC inverter spot welding machines, AC inverter spot welding machines, transistor spot welding machines, energy storage spot welding machines, etc.

2.More comprehensive measurement functions

Welding testing equipment can not only monitor the current of the resistance welding machine, but also the welding time and conduction angle data.

3.Excellent quality judgment ability

Equipped with welding quality judgment function, the upper and lower limit monitoring settings of key welding values ​​such as current, voltage, power, pressure, and displacement can be set. Once unqualified welding is detected, an abnormal alarm prompt will be issued to automatically detect unqualified products.

4.Powerful data traceability

Powerful database function can record welding data such as current, voltage, power, pressure, displacement, etc. for each welding, as well as historical alarm fault information, up to millions of items. Welding analyzer equipment also supports U disk export to form a table, which is more convenient for welding quality monitoring and quality tracking.

5.Counting and production monitoring function

Built-in multi-mode welding counter to meet the counting requirements of different welding workpieces in different occasions, and can also monitor the production.
